Box assembly glue machine

It is the necessary processing equipment for the medium and large enterprise which producing hardcover box, Luxury packaging manufactured.Depend on different kinds of design hardcover box, spray glue trail could be intelligent edit, sprayed on the hardcover or paperboard with different shapes glue trail. Use economic and reasonable amount glue, with precision spraying. Intelligent suction and position inner box and pressing, the inner box and hardcover glued together, Book shape hardcover gift box assembly complete.

High stability, Simple operation

PRODUCT DESCRIPTION

Feature

  1. PCL control, high stability with simple operation

  2. Spraying glue on to material part position

  3. Necessary machine for making hardcover box and other assembly box


hardcover box 05.png



Technical parameter


Box size (max / min)30MM*30MM~1000MM*700MM
production rate2200~3000PS/H
power of motor4500W
air input5~8kg/m2
Dimension3700*1400*2000mm
Machine weight(kg)750kg
Spray patternStraight lines, square, round, arc and other patterns
output1100-1500PS/H
Plate thickness3-25mm(adjustable)
Gray board length and width1000×700mm
Glue thickness1.5~4mm(adjustable)
The spray head2 symmetrical motions
Box setting station2
Glue heatingAbout 185 degrees at normal temperature
Adhesive weight1G~5G/S
Ac outputAC220V/380V
control systemIndependent R D
Programmingteaching programming

More Details




FAQ

Q1: Are you a factory or trade company?
A: We have our own factory, which located in Wuxi, with GRS, BSCl and SEDEX audit for over 5 years. We can provide OEM service including custom size and logo design.
Q2: How about quality control of your company?
A: We pay great attention on quality control from the beginning to the end,and our QC department will inspect all goods strictly before shipment delivery.Third party inspection is welcome.
Q3: When is your delivery time?
A: Within 30 days after ordering.
Q4:Is it all right to make customer brand name?
A: Yes, OEM is welcome if the quantity above the MOQ.
Q5: Where is your loading port?
A: Shanghai, China.
Q6:Do you supply free samples?
A:Yes, free stock samples will be available, but shipping cost will be covered by customers.Please contact us to check shipping cost according to customer's address.
